PFC Channels

Parallel Flange Channels.

Also know as C section, structural channel, or simply channel, this type of steel profile is useful in a variety of structural applications including floor beams, portal frames, trailer frames.

We offer a wide selection of parallel flange channels (PFC channels) to suit your project needs, and can supply them with next day delivery, guaranteed. You can depend on NE Steel to deliver products suitable for your needs.

Manufactured to the precise sizes and weights below, our PF Channels are suitable for a range of uses in residential and commercial builds.

Enquire

PFC Channels Specifications

Size mm Weight Kgm Depth (D) mm Width (B) mm Web Thk (t) mm Flange Thk (T) mm
150×75 18 150 75 5.5 10.0
150×90 24 150 90 6.5 12.0
180×75 20 180 75 6.0 10.5
180×90 26 180 90 6.5 12.5
200×75 23 200 75 6.0 12.5
200×90 30 200 90 7.0 14.0
230×75 26 230 75 6.5 12.5
230×90 32 230 90 7.5 14.0
260×75 28 260 75 7.0 12.0
260×90 25 260 90 8.0 14.0
300×90 41 300 90 9.0 15.5
300×100 46 300 100 9.0 16.5
380×100 54 380 100 9.5 17.5
430×100 64 430 100 11.0 19.0

Find a range of Steel products for any project with NE Steel.
